During the last several months we had the opportunity to sea trial four boats with Yamaha outboard motors in the 200 to 250 hp range. Two sets of these were on Grady-White 272 Sailfish, and another on a Pursuit 2855. This makes for a total of eight engines ranging in years from 1995 to 1999, which gave us a pretty good look at how these engines are performing over time. Compared to all the other engines, we were generally impressed at the superior performance of Yamaha engines.
First, we can tell you that none of the eight engines had had any major work done on them. This we can determine by looking at the painted bolt heads on the engines and see that no bolts had ever been turned.
[c12913] - Yamaha Ox66 225 Owners Manual thank you for choosing a yamaha outboard motor this owners manual contains infor mation needed for proper operation vz200 225 250 300 owners manual. SX150C SX200C OWNER’S MANUAL. Thank you for choosing a Yamaha out-board motor. Owner’s or operator’s manuals supplied. Yamaha Outboard Manuals 1984-1996 Yamaha 2hp to 250hp Repair Manual. All manuals are in pdf format for quick easy download. Do you have a 99 yamaha 200 ox66. Yamaha Outboard Service Information. Yamaha 2 Stroke Oil Tank Information. OX66 EFI 2 Stroke Maintenance Schedule. View and Download Yamaha MOX6 owner's manual online. Music Production Synthesizer. MOX6 Synthesizer pdf manual download. Also for: Mox8.
Another thing we look for is salt weeping from the cooling system and cylinder head gaskets. When that happens, it means that internal corrosion is taking place, and it's only a matter of time before some really bad things happen. None of our test engines revealed this problem, a very good sign indeed. We'd add these were Florida boats used in sea water 12 months per year.
Two were stored out of water, and two were permanently afloat, including the 5 year old engines. If you read the advertising, every manufacturer touts the latest and greatest high tech engineering that results in the greatest power, longest life, highest reliability and, of course, their engines hardly burn any fuel at all. And, of course, we all know that this isn't true. After all, outboards have a well-deserved reputation for being gas guzzlers, which is one drawback they can't overcome by virtue of the fact that outboards burn a combination of gasoline and oil.
That means that the fuel they burn is not as powerful as any engine that has a crankcase of oil for lubrication. That translates to having to burn more fuel to attain similar power outputs over a conventional gas engine. Add to this the fact that outboard propellers are not as efficient as inboard props and you have two good reasons why outboards burn more fuel. Regardless, it was the performance of these engines that really began to capture our attention. For one thing, outboards tend to be notorious for their inability to hold certain speed ranges. With many engines, if you want to go, say, 2600 RPM, the engine simply will not run at that speed. Yamaha Kt100 Manual. The engines will either want to surge forward to a faster speed, or fall off to a lower speed.
Well, it's mainly due to two things: less efficient propellers and low torque at low speeds. Another factor is carburetion. Here's one of the advantages of electronic fuel injection, which can precisely control the amount of fuel the engine receives, whereas a carbureted version cannot. In testing these four sets of engines on different boats, we were amazed at how well they could hold a speed. The 225 and 250 hp versions were best at this. Testing each at speed ranges in increments of around 500 RPM, we found that each would almost exactly hold that speed indefinitely without falling off or creeping ahead. This was aided by what we feel is the best set of engine controls in the business.
We've long complained about crappy engine controls. You probably know what I mean.
Those flimsy plastic jobs that feel like they're going to break off in your hand if you push on them two hard. In fact, a recent sea trail with a set of Mercury controls only 9 months old ended up with the idle control button stuck and jammed with the engine racing away out of control and no way to stop it. We compared those with the Yamaha engine controls which, although they are plastic, feel solid and function smoothly.
There was none of those poor tolerances that let the levers flop around in every direction. Indeed, when operating some of the competition's controls, we have to wonder how boat owners can tolerate such shoddy products. These Yamaha controls were a real pleasure to operate. Far and away, for us the biggest attention getter was the optional Yamaha instrument package which is just the neatest and most reliable set of outboard instruments we've run across. The digital tachometers have large, bright LED displays that permit very accurate speed control.
Then there is the bar graph tilt and trim readouts that, in the case of all eight engines still worked, even after as much as 850 hours and 5 years of use. That, we thought, was amazing considering the propensity of such gizmos to crap out after about the first year. And for the economy minded, 'the fuel management system,' which is nothing more than fuel flow meters a la Floscan meters, are great.
This allows you to determine at what speeds you're getting the best fuel economy. You discover nifty things like that at certain points the engines will burn less fuel at higher speeds than slower. Now, if this sounds like a virtual impossibility to you, it can be explained by the fact that nearly all boats have certain hull speeds that are more efficient than others. The fuel management system allows you find out exactly what speeds those are. Other features of interest are the motor covers. They are strong, heavy and well built. On most of the competitor's models, we find the latches to be clumsy and difficult to operate.
